• Power: 110V/60Hz; 220V/50Hz
• Air Source: 4 kgs/cm R
• Dimension: 1150 (L) x 700(W) x 1050(H) mm
• Net Weight: 145 kgs
• Capability: 18,000pcs/ Hour
• Shorten leads in the massive production to save the labor cost.
• If the leads were cut, the bowl feeder cannot run them because they
  falldown easily. Recommend to use AR-110 to cut shortened leads
  shorter.
• Lead Cutter can work independently from or together with the bowl
  feeder and supporting table. Hand Feeding is available when removing
  the bowl feeder.
• LED component Counter is available, please indicate on the order. The
  Lead Cutter Model No. with counter is CF-360.

Models:

1.- Multifunction:

• The body dia. / width is less than 10mm; the body height is less than 18mm apply to CF-366. (Such as middle/small-size Electrolytic
  capacitors, TO-92, LED, small film capacitors, etc.)
• Please provide at least 200 pieces of samples for evaluation and test
  running.
• Power Transistor/MOSFET TO-220 (cubic shape) must use a specialized
  single function bowl feeder.

2.- Specialized Single Function:

• Each shape for one single bowl. Please provide 200 pcs of each part to customize the bowl feeder. Longer Lead Time.
