Saturn 3D

SPI:

3D solder paste inspection with dual projection and warpage compensation. Its ability to inspect in real time and control process quality makes it an essential tool for electronics manufacturing.

Dual and Quad Projection
Real Color 3D
Warpage compensation
Foreign Object Inspection
Smartron (remote control and web control)
Real time process and quality control solutions.

Model			Saturn
2D/3D Vision Algorithm			2D: Vision Inspection Algorithm 3D: PMP (Phase Measuring Profilometry) Algorithm
Measurements			Volume, Height, XY Position, Area
Detecion Types			Insufficient Paste, Excessive Paste, Shape Deformity No Paste, Bridge 2D&3D, Paste Displacement
X/Y Pixel Resolution			4MP			10MP
			10um	15um	18um	10um	15um
Inspect Speed			9.1 cm2/sec	20.5 cm2/sec	29.5 cm2/sec	38.4 cm2/sec	86.4 cm2/sec
FOV (Field of View)			20 x 20mm	30 x 30mm	36 x 36mm	32 x 30mm	48 x 45mm
Height Range			0.45mm (Optional: Up to 2mm)
Height Accucary			2/um*
Gantry Type			Linear Motors
PCB Specification	Inspection Size	Standard	Min. 50 x 50mm (2 x 2 inch) Max. 330 x 330mm (13 x 13 inch)			Single	Min. 50 x 50mm (2 x 2 inch) Max. 330 x 500mm (13 x 20 inch)
						Dual	Max. 330 x 280mm (13 x 11 inch)
		Large	Min. 50 x 50mm (2 x 2 inch) Max. 510 x 510mm (20x 20 inch)			Single	Min. 50 x 50mm (2 x 2 inch) Max. 510 x 600mm (20 x 24 inch)
						Dual	Max. 510 x 330mm (20 x 13 inch)
	Thickness		0.4 ~ 7mm
	Bottom Clearance		27mm
Electrical Requirements			200 ~ 240VAC, 50/60Hz
Power Consumption			Standard Type			2.1kW (9.68A Max @ 220V AC)
			Large Type			2.3kW (10.9A Max @ 220V AC)
Machine Dimension	W x D x H / Weight (Standard)		900 x 1240 x 1600mm (35 x 49 x 63 inch) About 750kg (1653lbs)
	W x D x H / Weight (Large Type)		1080 x 1410x 1600mm (42 x 55 x 63 inch) About 950kg (2094lbs)
